Finned Air Cartridge Heater
Finned Air Cartridge Heater by LICHENGDA. Airflow and fin clearance, configuration details and made-to-drawing quotation for air ducts, dryers and equipment enclosures.
Product image gallery (7)
PRODUCT ENGINEERING
Airflow and fin clearance
Finned Air Cartridge Heater: Fins transfer heat to passing air. State the air speed, inlet temperature and duct dimensions before selecting surface loading; a wattage alone does not establish the allowable air temperature rise.
Keep fins clear of cables and combustible material. Review fan-failure interlocking and place the temperature limit where reduced airflow will be detected.
For Finned Air Cartridge Heater, request the missing voltage, power and finished dimensions before calculating current, selecting a supply or fixing the mounting pattern.
The archived configuration for Finned Air Cartridge Heater lists Outer Sheath Material: Stainless Steel 201.2520.304, 321, 316;; Resistance Heating Wire: NiCr 80/20 wire; Voltage Available: 12V, 24V,48V,60V, 110V,230V,380V,480V. and other customized; Length Tolerance: ±2%. Treat these as reference options and reconcile them with the named configuration and installation drawing before quotation.
For Finned Air Cartridge Heater, send the supply, continuous and peak temperature, mounting drawing, lead exit and quantity. Include the heated medium and control method so the quoted configuration can be checked against the actual duty.
Application and reference configuration
Air ducts, dryers and equipment enclosures. The final suitability of Finned Air Cartridge Heater depends on the assembled equipment and agreed operating conditions.
Archived figures below describe reference options or a product series. Confirm the exact model specification in the quotation.
| Outer Sheath Material | Stainless Steel 201.2520.304, 321, 316; |
|---|---|
| Resistance Heating Wire | NiCr 80/20 wire |
| Wattage Tolerance | +5%, -10% |
| Resistance Tolerance | +10%, -5% |
| Maxium Heating Temperature | 800 Degree Celsius |
| Voltage Available | 12V, 24V,48V,60V, 110V,230V,380V,480V. and other customized |
| Length Tolerance | ±2% |
| Diameter Tolerance | ±0.02mm |
| Standard Cold Size | 5-10mm |
| Insulation Resistance (cold) | ≥ 500 MΩ |
