THIN, LIGHT & UNIFORM
150W Silicone Heater Pad
150W Silicone Heater Pad by LICHENGDA. Surface contact and flexible circuit layout, configuration details and made-to-drawing quotation for surface warming and compact equipment assemblies.
Product image gallery (7)
PRODUCT ENGINEERING
Surface contact and flexible circuit layout
150W Silicone Heater Pad: Define the heated outline, substrate material and mounting method. Continuous contact supports uniform heat transfer; air pockets, folds or partial bonding can produce local hot spots.
Keep the active circuit clear of fasteners and sharp bends. Confirm adhesive compatibility, lead strain relief and sensor location at the substrate rather than selecting power from pad area alone.
For 150W Silicone Heater Pad, use the listed 150W as catalog identifiers and confirm the complete electrical and dimensional combination before calculating current, selecting a supply or fixing the mounting pattern.
The archived configuration for 150W Silicone Heater Pad lists Power density: 0.10~1.50w/cm²; External insulation material: Silicone glass fiber; Voltage: 3.7-660V. Treat these as reference options and reconcile them with the named configuration and installation drawing before quotation.
For 150W Silicone Heater Pad, send the supply, continuous and peak temperature, mounting drawing, lead exit and quantity. Include the heated medium and control method so the quoted configuration can be checked against the actual duty.
| Catalog name values | 150W |
|---|
Application and reference configuration
Surface warming and compact equipment assemblies. The final suitability of 150W Silicone Heater Pad depends on the assembled equipment and agreed operating conditions.
Archived figures below describe reference options or a product series. Confirm the exact model specification in the quotation.
| Temperature range | -40.00~180.00°C |
|---|---|
| Electric resistance precision | ±10%( bigger value selected) |
| Power density | 0.10~1.50w/cm² |
| Mechanical pressure | 100.00kg/cm² |
| Minimum bending radius | 3.20mm |
| External insulation material | Silicone glass fiber |
| Internal heating element | Ni-Cr alloy |
| Thickness | 1.5mm-3mm(With 3M) |
| Voltage | 3.7-660V |
ARCHIVED PRODUCT INFORMATION
Description
Flexible Rubber Silicone Rubber Belt Pipe Heater are available as wire wound or etched foil. Wire wound elements consist of the resistance wire wound on a fiberglass cord for support and stability. Etched foil heaters are made with a thin metal foil (.001") as the resistance element. Wire wound is recommended and preferred for small to medium size quantities, medium to large sized heaters, and to produce prototypes to prove out the design parameters prior to entering into large volume production runs with etched foil.
【120V Engine Heater Pad Quick Warm Metal Surfaces】Silicone engine heater pads are designed to protect engine car oil pan and metal surfaces freezing on cold winter days. Engine heater provides flow oil of tank for RV, Camper, Mobile home, Boat, Truck,Trailer, Marine in winter.
【Engine Heater Pad Heats Quickly and Effectively in seconds】Silicone engine heater pads are designed to protect engine car oil pan and metal surfaces freezing on cold winter days. Engine heater provides flow oil of tank for RV, Camper, Trailer, Mobile home, Boat, Marine in winter. Engine heater pad works great for heating automatic defoamer and keeps oils warm, making drivers easy to start their vehicle on cold mornings.
| Temperature range | -40.00~180.00°C |
| Electric resistance precision | ±10%( bigger value selected) |
| Power density | 0.10~1.50w/cm² |
| Mechanical pressure | 100.00kg/cm² |
| Minimum bending radius | 3.20mm |
| External insulation material | Silicone glass fiber |
| Internal heating element | Ni-Cr alloy |
| Thickness | 1.5mm-3mm(With 3M) |
| Voltage | 3.7-660V |
|
120V 150W Electric Heating Pad Silicone rubber substrate imported from USA 5X4-inch thickness:1.8mm Silicone heater pad can attach any metal surface. |
3M adhesive backing offers excellent and easy mounting onto most surfaces. Versatile and may be used in many other applications. |
6.56-foot (2-meter) power cable , ensure maximum reach; 120V, 2 prong power plug can plug into any wall outlet |
|---|
【120V Engine Heater Pad Quick Warm Metal Surfaces】Silicone engine heater pads are designed to protect engine car oil pan and metal surfaces freezing on cold winter days. Engine heater provides flow oil of tank for RV, Camper, Mobile home, Boat, Truck,Trailer, Marine in winter.
【Engine Heater Pad Heats Quickly and Effectively in seconds】Silicone engine heater pads are designed to protect engine car oil pan and metal surfaces freezing on cold winter days. Engine heater provides flow oil of tank for RV, Camper, Trailer, Mobile home, Boat, Marine in winter. Engine heater pad works great for heating automatic defoamer and keeps oils warm, making drivers easy to start their vehicle on cold mornings.
【Ease of Installation】Clean the surface; Peel off the backing paper in brown color; apply the heater pad to the surface cleaned making sure no gap or air bubbles trapped under the pad. Seal the edges of the pad with high temperature silicone RTV sealant. (Not included), plug power cord into any wall outlet.
【12- MONTH WARRANTY】Warranty of one year since purchase date is offered. Every and each item is tested and made sure in good condition before shipment. Mal-functions due to mis-use or man made damages are not included in this warranty. Due to manufacture reasons, stains on surface do not affect the function and life time.
【Built to Last】Engine heater pad made of high quality material which is flexible,thin,moisture proof and quick heat transfer in seconds; Caution-Extremely hot, do not touch it!!!
Digital temperature control: Temperature control range -45 ℃~220 ℃. It can maintain a constant
temperature or a temperature range, and the temperature can be adjusted
Knob temperature control: commonly used temperature ranges are 0-40 ° C, 0-60 ° C,
0-120 ° C, 30-110 ° C, 30-150 ° C, 50-200 ° C etc. Temperature adjustment can be installed at
any position on the heating plate, with average temperature control accuracy, suitable for
insulation and antifreeze industries that do not require high temperature control accuracy.
Constant temperature control: also known as temperature switch/overheat protector. Generally,
there is a temperature range of 5 ℃, with commonly used temperatures including 5 ℃, 10 ℃, 20 ℃,
30 ℃, 40 ℃, 45 ℃, 50 ℃... 180 ℃, etc. The temperature can be adjusted but not adjustable. It can
be installed at any position on the heating plate and cannot be externally connected. The
temperature control accuracy is average, suitable for insulation and antifreeze industries that do not
require high temperature control accuracy.
Company profile
Xiamen Lichengda Precision Manufacturing Co., Ltd. was established in 2 0 1 2 year. It is a
comprehensive company integrating production, sales and technical service. the factory covers an
area of 5000m2, has nearly 100 employees. Applicable quality-system and product-compliance documentation must be confirmed for the quoted product, legal entity and current scope.
Main products : cartridge heater,Tubular heater, Flexible heater, cartridge heater,silicone heater
thermocouple, heating element, and other heating products. The factory introduced advanced
automatic control system and online quality,inspection system to ensure the stability and reliability
of product quality
1. Qucik Response:Your inquiry will be replied within 24 hours. Response Rate over 90%
2. Smooth Communication: Well-trained and experienced staffs to answer all your inquires.
3. Sincere Service Attitude: Treat Customers As Friends. No Questions are Neglected.
4. OEM Accepted: Free Sample,We can customize your products to meet all your different requests.
5. Small MOQ: Small Amount wholesales are supported to meet your needs as well as large demands.
6. Fast Delivery: We have Reliable Forwarders with long term cooperation and Competitive Price.
You may contact any one of our sales and services team: email to us as inquiry.
Hot Tags: 150w silicone heater pad, China, manufacturers, suppliers, factory, wholesale, customized, cheap, in stock, free sample, Flexible Kapton Film Polyimide Heater, 12v flexible pi kapton foil heater, custom flexible silicone pad heater, Ceramic Pad FCP Heater, silicone rubber heater heating element, electric silicone drum heater bands
Specifications and availability vary by configuration. Confirm dimensions, materials and electrical or measurement ratings in your quotation.
