ACCURATE TEMPERATURE SENSING
Meat Thermometers For Grilling
Meat Thermometers For Grilling by LICHENGDA. Thermocouple alloy and junction selection, configuration details and made-to-drawing quotation for industrial temperature monitoring and furnace control.
Product image gallery (5)
PRODUCT ENGINEERING
Thermocouple alloy and junction selection
Meat Thermometers For Grilling: Match thermocouple type, polarity and extension cable to the controller input. Select protection-tube material and grounded or ungrounded junction for the atmosphere, electrical noise and response required.
Define insertion depth and the mechanical support at the process connection. A temperature stated in a product name needs confirmation for the complete probe assembly, cable transition and continuous duty.
The archived configuration for Meat Thermometers For Grilling lists tube diameter: Customized; Probe Material: 304 stainless steel. Treat these as reference options and reconcile them with the named configuration and installation drawing before quotation.
For Meat Thermometers For Grilling, send the controller input, required measurement range, accuracy, probe drawing and cable or connector details. Ask for the agreed sensor designation and inspection requirements on the quotation.
Application and reference configuration
Industrial temperature monitoring and furnace control. The final suitability of Meat Thermometers For Grilling depends on the assembled equipment and agreed operating conditions.
Archived figures below describe reference options or a product series. Confirm the exact model specification in the quotation.
| tube diameter | Customized |
|---|---|
| K type | -50-500℃ |
| PT100/PT1000 | -50-200℃ |
| Probe Material | 304 stainless steel |
| Wiring terminal | 2 wire (K),3 wire or 4 wire (PT100) |
ARCHIVED PRODUCT INFORMATION
Description
FEATURES OF PROBE.
Stainless steel cable is 4.1 feet (1250mm) long.
Probe is 7 inches (178 mm) long and has a probe tip to R angle of 6 inches (153 mm).
Probe diameter of 0.2 inches (5mm), and a probe tip of 0.4 inches (10mm).
Plug has a diameter of 3.5mm (0.14inches) and a length of 0.55inches (14mm).
Probe can withstand temperatures up to 1000°F (500°C).
Stainless steel cable can withstand temperatures up to 718℉(380℃).
Replacement for Pit Boss Meat Probe: Compatible with Pit Boss Pellet Grills and Pellet Smokers with digital control meat probe capability. For use with all meats, great replacement probe or additional probe.Premium meat probe uses precision high temperature thermistors and comes from the world's top suppliers. 3.5mm Plug Compatible with Pit Boss Accessories Meat Probe.
Features of the Meat Probe: We use a 3-layer compression interface (stainless steel cable and probe connection location) to make our probes more waterproof and more rugged, as well as IPX7 and waterproof probes and stainless steel cable. The meat probe is made of food grade stainless steel. Monitor meat temperature or grill temperature. The buck probe design provides accurate, fast temperature sensing and alerts you to temperature changes in seconds.
Professional Manufacturer: We have 20 years of experience in the BBQ meat thermometer probes and meat probe,providing temperature sensors or probes for most of the world's leading thermometer brands. Please note: Our thermometer probes only support the listed models. If you accidentally bought the wrong probe, please let us to replace or provide a refund service. In order to extend the life of the temperature probe, we recommend that you clean it with a rag after use.
Meat Probe Parameters: Stainless steel cable is 4.1 feet (1250mm) long. The probe is 7 inches (178 mm) long and has a probe tip to R angle of 6 inches (153 mm), a probe diameter of 0.2 inches (5 mm), and a probe tip of 0.4 inches (10 mm). The plug has a diameter of 3.5mm (0.14inches) and a length of 0.55inches (14mm). The probe is bent (R 25°). The probe can withstand temperatures up to 1000°F (500°C), the stainless steel cable can withstand temperatures up to 718℉(380℃)
A penetration thermocouple (or penetration probe thermocouple) is a specialized temperature sensor designed to measure the internal temperature of solid or semi-solid materials, such as food products. These probes are commonly used in food processing, cooking, and quality control to ensure proper heating, cooling, and safety compliance.
|
tube diameter |
Customized |
|
K type |
-50-500℃ |
|
PT100/PT1000 |
-50-200℃ |
|
Probe Material |
304 stainless steel |
|
Wiring terminal |
2 wire (K),3 wire or 4 wire (PT100) |
Key Features of Penetration Thermocouples for Food
1:Stainless Steel Construction – Food-grade (often 316SS) for hygiene and corrosion resistance
2:Sharp or Needle-like Tip – Allows easy insertion into meat, dough, frozen products, etc
3:High-Temperature Range – Typically measures from -50°C to 500°C
4:Fast Response Time – Thin probe design ensures quick readings (important for HACCP compliance)
5:Waterproof & Easy to Clean – Some are IP67-rated for washdown environments.
Advantages of Penetration Thermocouple Thermometers for Food
1. Accurate Core Temperature Measurement
Direct Penetration Design: The only tool capable of accurately measuring the internal temperature (not just the surface) of food, ensuring sterilization/cooking compliance.
HACCP Compliance: Meets the strict temperature monitoring requirements for critical control points in food safety systems.
2. Rapid Response Time
Ultra-Fast Readings (3-5 seconds): 50% faster than standard probes, ideal for:
High-speed production line inspections
Real-time monitoring in deep fryers/ovens
Tracking thawing processes in frozen products
3. Food-Grade Safety Design
316L Medical-Grade Stainless Steel: Corrosion-resistant and withstands high-temperature sterilization (up to 150°C steam cleaning).
Seamless Construction: Prevents bacterial growth, certified by FDA/EC1935 for food contact materials.
4. Superior Environmental Adaptability
Wide Temperature Range (-50°C to 500°C): Suitable for:
Cold storage monitoring (-18°C)
Deep-fryer temperature control (250°C)
Fermentation chamber regulation
IP67 Protection Rating: Resists high-pressure water washing, perfect for wet environments like meat processing.
5. Industrial-Grade Durability
500,000+ Penetration Tests: Optimized for meat inspection.
Break-Resistant Design: 2mm ultra-thin probe maintains 3kgf bending strength.
6. Smart Expansion Capabilities
Optional features:
Bluetooth data logging (automatic HACCP records)
Audible alarms (instant temperature alerts)
Laser positioning (assists precise insertion points)
Common Applications in the Food Industry
Meat & Poultry Processing – Checking internal temps for safety (e.g., USDA guidelines).
Bakery & Dough Products – Monitoring core temperature during baking.
Dairy & Cheese Production – Ensuring pasteurization and fermentation control.
Frozen Foods – Verifying storage & thawing temperatures.
Cooking & Catering – Used in professional kitchens for precise doneness checks.
